on, the carbon is surroundedby an oxide of manganese. Sometimesthe carbon and the oxide of manganeseare placed in a porous cup. The E.3LF.is about 1.1 V. Arrangement of Cells. — If we havesix cells, they may be connected in twoways, in series (Fig. 23), that is, thecopper of one to the zinc of the… … Fig. 23. 66 PHYSICAL MEASUREMENT. the same as for a single cell, but the internal resistanceis divided by six. Then, from Ohms law, if E is the E.3T.F. of one cell, r its internal re-+^ j- sistance, 11 the resistance of the rest of the circuit, and O the current, — (Series) C = — 6E (Multiple Arc)…
