Austin, Louis W. (Louis Winslow), 1867-1932, Thwing, Charles B. (Charles Burton), 1860-1946, joint author · Boston, Allyn and Bacon · leaf 84
eter, it may be placed in ashunt, and the fraction of the current passing throughwill be determined by the ratio of the resistance of thegalvanometer and that in the other arm of the shunt. Bythe law of shunts, —C, fitC2 iVwhere 0 is the current and Ris the resistance. The Resistance-Box is awooden… … 72 PHYSICAL MEASUREMENT. as the plugs, Pn P2, have a resistance so small that itmay be neglected in comparison with i?19 722. Whenthe plugs are all inserted, the resistance of the box isreckoned as zero. When P1 is removed, a resistance Rxis put into the circuit, AB. The resistance of the coilsis…
Physics
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
