nged to be worked by a suitable cam rod attached to theouter crank d. The terminal, c, is stationary and insulatedfrom the cylinder-wall. The two terminals may be mounted §454.] HOT-AIR AND GAS ENGINES. 6325 in a removable plug P. The extremities of the terminalsshould be of some metal, as… … Fig. 248c.—Jump-spark Ignition. by Fig. 248^. Both igniter terminals are stationary andmounted in a plug of insulating material, usually porcelain orlava. These are connected to the secondary terminals, s, s,of an induction-coil. The primary circuit of this coil is con-nected to a battery, B, at…
