Experimental engineering and manual for testing. For engineers and for students in engineering laboratories (1906)
Carpenter, Rolla C. (Rolla Clinton), 1852-1919 · New York, J. Wiley & Sons; [etc., etc.] · leaf 129
Fig. 44- Fig. 45. Fig. 46. Fig. 46 is a sectional view of same. Fig. 44 5s a view ofthe wedge-faced clamp. The inclination of the surfaces of thewedges are exaggerated in the drawings,so as to distinctly setforth their features. Wedges have been made with spherical backs, and a por-tion of the…
