Experimental engineering and manual for testing. For engineers and for students in engineering laboratories (1906)
Carpenter, Rolla C. (Rolla Clinton), 1852-1919 · New York, J. Wiley & Sons; [etc., etc.] · leaf 557
screen or on a sensitive plate in a camera. Theform of the diagram may be studied by observing it on the groundplate, or it may be photographed and preserved. One form of this instrument is made by J. Carpentier ofParis, and is called the Manographie. Another form is made bythe Elsassische… … Fig 239- back part of the camera E. It is deflected in one direction bya small crank operated in unison with the engine piston by the revolving shaft. P, to1^1^^ which it is connected bythe flexible shaft R, Fig.239; it is deflected in adirection at right anglesagainst the resistance ofa spring by…
