ented by abscissae. * Rankines Steam-engine, page 385. f See Thurstons Engine and Boiler Trials, page 251. § 4o6.] THE INDICATOR-DIAGRAM. 557 In the figure the curve A to G is the hyperbola, A to / thesaturation curve, and A to L the adiabatic curve. ON is theaxis of the hyperbola, of which OB and… … 1800 1700 1600 1500 1400 1300 1200 1100 1000 900 800 700 600 500 400Fig. 262.—The Three Expansion Curves. 300 300 to a condition in which the moisture is decreasing, the latteragreeing more closely with the actual condition. 406. Weight of Steam from the Indicator-diagram.—The diagram shows by…
