Experimental engineering and manual for testing. For engineers and for students in engineering laboratories (1906)
Carpenter, Rolla C. (Rolla Clinton), 1852-1919 · New York, J. Wiley & Sons; [etc., etc.] · leaf 60
egrated 26.] APPARA TUS. 31 It also carries a wheel, whose axis is in the same vertical planewith the arm KF, and which may be located indifferently be-tween AT and F, or in KF produced. It is usually located in KF,produced as at D. The rim of this wheel is in contact withthe paper, and any motion… … Fig. 4.—Amslers Polar Planimeter. The detailed construction of the record-wheel, and the ar-rangement of the counter G, showing the number of revolutions,
