The total heat received and discharged per stroke is obtainedby testing. The distribution of the heat and its relations to thework performed is obtained by measurements from the indicatordiagram. For this purpose the diagram is divided as indicatedin Fig. 282, so that the mechanical work for the… … Fig. 282.—Diagram from a Greene Engine. Cylinder, 26 inches in diameter by36 inches stroke. boiler-pressure, 80 revolutions per minute. scale, so. work expressed in heat-units done during that period. Fromthis comparison the amount of heat interchanged, plus or minus,is computed for each period. It…
