Experimental engineering and manual for testing. For engineers and for students in engineering laboratories (1906)
Carpenter, Rolla C. (Rolla Clinton), 1852-1919 · New York, J. Wiley & Sons; [etc., etc.] · leaf 699
nimeter. In Fig. 297 the inertia-diagrams for forward and backwardstrokes have been separated. The negative and positive signsshow respectively where the inertia opposes and assists thesteam-pressures. The curve yy belongs to the forwardstroke and yy to the return. In practical use the diagram… … 01 2 3 4 5 6 7 8 9 10 0 7ig. 298.— Crank-positions corresponding to given Piston-positions. piston and crank obtained. The method of dividing the dia-gram shown in Fig. 297 is convenient in transferring the curveto a steam indicator-card similarly divided. Care being takento draw both to the same…
