Experimental engineering and manual for testing. For engineers and for students in engineering laboratories (1906)
Carpenter, Rolla C. (Rolla Clinton), 1852-1919 · New York, J. Wiley & Sons; [etc., etc.] · leaf 752
en two cylinders, as a compound or two-stage com-pressor; when three cylinders, as a three-stage compressor, etc. A section of a two-stage compressor with mechanically oper-ated inlet-valves, driven by a direct-connected steam-engine, is shown in Fig. 325. The air is first drawn into the large 720… … Fig. 323.—Air-compressor Cylinder. To remove the heat generated during compression, the cylin-ders are usually jacketed with water, and in multiple-stage com-pressors the air is further reduced in temperature by passing
