Experimental engineering and manual for testing. For engineers and for students in engineering laboratories (1906)
Carpenter, Rolla C. (Rolla Clinton), 1852-1919 · New York, J. Wiley & Sons; [etc., etc.] · leaf 752
Fig. 323.—Air-compressor Cylinder. To remove the heat generated during compression, the cylin-ders are usually jacketed with water, and in multiple-stage com-pressors the air is further reduced in temperature by passing … Pig. 324.—The Ingersoll Air-compressor. through a vessel called an intercooler, which is located betweenthe cylinders, and through which water is made to circulate innumerous small pipes. 722 EXPERIMENTAL ENGINEERING. f § 467 w,
