Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 103

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 103
235. NOVEL REDUCING VALVE. Holly type, having a large area and lap ofa flat valve disk. The relative difference ofpressure is regulated by the free hangingweights under the disk, while excessive backpressure tends to close the valve by pressureon the large area of the back of the disk. The wheel… … 236. DIFFERENTIAL EXHAUSTVALVE. For regulating the back pressureon the engine in exhaust steam-heatingsystems. The two-winged valves are nearly bal-anced, requiring only a small weight to bal-ance them and prevent chatter of the valves. STEAM POWER APPLIANCES. lOI 237. AUTOMATIC QUICK-CLOSING…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
