A C to Z>, where its tangent OD becomesparallel to B K, and consequently the radius DE parallel to B F.Then if the chords CD and CB be drawn, we have the angle CED= CFB; whence E CD, the half-supplement of CE D, is equal toFCB, the half-supplement of CFB. But E CD cannot be equal toF CB, unless… … !S)lution. Let AI and Bl (fig. 11) be the tangents of the curve.Through the intersection point 7, draw IM bisecting the angle A IB.Draw A L and B M perpendicular respectively to A I and B /, niect-ing 1M in L and M. Then the radius of the branch commencing onthe shorter tangent A /must be less than…
