First principles of mechanical and engineering drawing (1897)
Holt-Butterfill, H · London : Chapman & Hall · leaf 183
3. The next case is that of the intersections of unequal cylinders,at an angle other than a right angle, and having their axes in differentplanes at a given distance apart. The problem is— Problem 77 (Fig. 180).—Two cylinders of unequal diameter, withtheir axes in parallel planes, intersect each… … MECHANICAL AND ENGINEERING DRAWING 171 As one of the cylinders is inclined, an elevation of both as if theywere entire must first be drawn, as shown in No. 1. From this obtainby direct projection the plan of the solids as given in No. 2. Then tofind the visible lines of intersection, assume…
Mechanical drawing
