Perspective and geometrical drawing : adapted to the use of candidates for second and third-class teachers' certificates (1887)
McGuirl, Thos. H. (Thomas H.) · Toronto, Ont. : W. Briggs · leaf 54
= AC and FX = DE ;make PG = FX and GH = GA ; join HKMP, GLMP, A C.V., THE HEXAGON. 51 1) C.V.j E C.V. and C C.V. At K, L erect perpendiculars tomeet vanishing lines in N and M ; join MR, MD, LE andLP : then RMDELPR will be hexagon required. For AK =AH and AL = AG = FX = 2, and DE = RP and ML = NK… … ol DRAWING. Draw H.L., B,L., and find O C.V. and MP as before.Make SV and ST each = 1, and make TX and VA each = 1;make AF = 2, and draw it J_ to AX; draw XP, TY, VZparallel to AF. Make RG = RL or TV, and GZ also = RL,and complete the oblong MH. Make An = AF, Ab = AG andAE = AH; join EMP, 6MP, «MP,…
Geometrical drawing · Perspective
