First principles of mechanical and engineering drawing (1897)
Holt-Butterfill, H · London : Chapman & Hall · leaf 215
mi-circle cutting the IL in b and c ;and through those points draw lines parallel to a a. On the axialline, set off from a the intended length of the cylinder, and throughthe point thus given, draw the line d c parallel to b c ; then d bee will bethe elevation of the cylinder. Next, divide the… … Fi(J. 199
Mechanical drawing
