n this 15-tooth gear=2J^In a 15-tooth gear, the arc, O ^, passes through thecenter O, but for a gear having any other number ofteeth, this construction arc does not pass throughcenter of gear. Of course, the 15-tooth radius of arcs,A K and O h, is always taken from the pitch we areworking with. 26…
