Vignola, 1507-1573, Juglaris, Tommaso, Locke, Warren S · [Boston, Press of Berwick & Smith] · leaf 39
rts by points. Place one leg of a pair of compasseson one of these points, and with a radius equal to the chordbetween two adjacent points on the circumference, makean indefinite arc outside the circumference. Reverse the position of the legs of the compasses, andmake another arc, cutting the… … PLATE Vili. THE DORIC CAPITAL AND ENTABLATURE.FiKST Style. This example of the Doric Order is taken from thetheater of Marcellus in Eome, and has the same propor-tions. Vignola gives the Doric capital a diameter, in thebody, of If moduli, a height of 1 modulus (exclusive ofbead at top of column),…
Architecture
