er, whatever license is taken with the triglyphand metope, the centers of triglyph and column must be inline with each other. The height of the cornice is mod-uli, and it projects 2 moduli. The mouldings will be under-stood from the illustrations. The plan of the under side(Soffit) of the… … PLATE IX. THE DORIC CAPITAL AND ENTABLATURE.Second Style. For this modification of the Doric Order, Yignola usedmany fragments from ancient Roman architecture. The differences between this and the first style are in thecapital, architrave, and cornice. In the place of the threelittle fillets of the…
