Vignola, 1507-1573, Juglaris, Tommaso, Locke, Warren S · [Boston, Press of Berwick & Smith] · leaf 63
s high andprojects 8 parts. The plinth is 5 moduli high, includingtwo fillets. It is 2 moduli and 14 parts wide. The cap isi modulus high and projects 10 parts. The outline is givenwith full dimensions. Concerning the Column. The base of the column is 1 modulus high and projects7 parts. Vignola… … PLATE XIV. THE IONIC CAPITAL. In this capital the volutes are of such construction thatthe fillet and bead, which properly belong to the column,are included in the construction of the capital, making it 15instead of 12 parts high. The fillet is 1 part, and the bead2 parts, high. The quarter-round…
