Vignola, 1507-1573, Juglaris, Tommaso, Locke, Warren S · [Boston, Press of Berwick & Smith] · leaf 95
ded square, havingdiagonals 4 moduli long. On one side of this square con-struct an equilateral triangle. The outside angle of this triangle will be the center foran arc of a circle forming one side of the table. The plan and elevation, together with this description,are suflicient to make the… … PLATE XXII. THE CORINTHIAN ENTABLATURE, This Entablature is taken from various places in Eome,but chiefly from tlie rotunda of the Forum. The total height is \ the height of the column, with baseand capital, or 5 moduli, divided in the proportions 3, o,and 4. The architrave is l^- moduli high…
Architecture
