s been followed carefully by thereader, he will see that there are but three lines of movementin the whole narrowing operation proper, though on two of 120 FLAT MACHINE KNITTING AND FABRICS these lines the movement is in opposite directions at differenttimes. To do this automatically only three… … Back of Automatic Narrowing Machine Showing Shaft Carrying Cams forAutomatic Moveinents. View from Right End of Machine. The source of all of these movements is the shaft uponwhich the bevel gear (Figs. 75 and 81) is mounted and isdesignated by the number 9 in Figs. 75, 79 and 80. It may beplainly…
