Buck, H. D. (Horace Davis) · New York, Bragdon, Lord & Nagle Company · leaf 135
of needles or their relative positionsmust be changed each course. In this fabric the design is brought out on one side only,the back plate, and the needles on the opposite side or frontplate are knitting each time the carriage is moved across themachine as explained in detail later. This may be… … 134 FLAT MACHINE KNITTING AND FABRICS photographic reproduction of the cam system used in thismachine; also to Fig. 90, which is a drawing of a cross sectionof the needle plates. It will be noted in Fig. 90 that thereare two separate needle plates. The top one is for the needlesproper, while the…
Machine knitting · Textile fabrics
