chain back and forth aroundthe sprockets. This arrangement gives the carriage a uniformmovement during the time it is operating the needles and isgenerally conceded as superior to the crank system of driving.The letter G, Fig. 45, indicates the lever for throwing inthe clutch to start the machine,… … Fig. 46Automatic IMechanism, Dubied Machine AUTOMATIC LATCH NEEDLE MACHINES 59 indicate the racking chains. These will be taken up in moredetail later. Letter B indicates an ingenious counter arrange-ment for counting the rounds, which permits the use of veryshort chains and will be explained in…
