Buck, H. D. (Horace Davis) · New York, Bragdon, Lord & Nagle Company · leaf 69
eof the best methods is the cylinder or drum idea devised byDubied & Co., which is shown in Fig. 50. To more easilymaster the explanation of how this cylinder operates, it shouldbe understood that its only function is to count the rounds andstart the main chain at the proper point, the chain… … Fig-. -Counting- Drum for Short Chain Arrangement, Dubied Machines. grooves, the larger of which is used to attach stops and thesmaller to act as a guide for the fingers i and j, which extenddown into and run in the narrow groove and carry the wholeblock, including the forks k and I, forward or…
Machine knitting · Textile fabrics
