Free-hand drawing : a manual for teachers and students (1904)
Cross, Anson Kent, 1862- · Boston : Ginn · leaf 122
already shown, it does not represent the SCIENTIFIC PERSPECTIVE AND MODEL DRAWING. 105 appearance of the objects in the room unless the eye is at the station-point, which, in Fig. 43, is about 3 from the paper, and oppositepoint CV. It gives, however, the positions of the objects withreference to… … Fig. 43. A .Satisfactory Representation of One Wall. centre of the picture. The station-point for this drawing is about3^ from CV. There is no reason why these objects should bedistorted, and if the picture plane is placed at right angles to ahorizontal line from the eye to the centre of the…
Drawing
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
