ines perpendicular to the wall vanishat point CV\x\ AB \ therefore, the drawing is unsatisfactory, for all I04 FREE-HAND DRAWING. at the left of AB is outside of both vanishing points, and mostunpleasantly distorted. Fig. 36 shows the same distortion in theleft part of the bureau. The station-point… … Fig. 42. A Satisfactory Representation of One Wall. left of the left vanishing point can be shown. Fig. 42 representsthe wall when thus seen and is a satisfactory drawing. Like anyperspective it requires, however, to produce the same image as theobject, to be seen from the station-point, which is…
