ls. io6 FREE-HAND DRAWING. Fig 46 represents three Avails of a room, the picture plane beingat right angles to a line from the eye to the centre of the subject.As the eye is nearer the wall at the left than that at the right, thehorizontal lines of the end of the room are at an angle to the… … FiG. 44. An Unsatistactor} Drawing. point opposite CFand about 3 from the paper it will not appeardistorted. Fig. 47 is a perspective drawing on a plane parallel to the endof the room. It is the best drawing that can be made, and illus-trates Rule 32 ; its station-point is about 3 from the centre…
