Freehand perspective and sketching; principles and methods of expression in the pictorial representation of common objects, interiors, buildings and landscapes (1916)
Norton, Dora Miriam · Brooklyn : The author · leaf 109
Fig. 145 a church spire or a tower (Fig.145) stand true will be readilyrecognized. The use of the di-agonals (AB and CD) will aidin placing its axis and apex. Any upright rectangular ob-ject with equally sloping sides iseasily constructed on the sameprinciple, as the grape basket inFig. 145a. If… … 6PAPr-BA«K»T Fig. 143a 90 Chapter XXVI THE SQUARE FRAME LEANING ON THE RECTANGULAR BLOCK —A PROBLEM FOR ORIGINAL STUDY THE Models. — These have ah^eady been described on pages48 and 85, respectively.Position— The block rests on one long face, with itssquare ends making angles of sixty degrees with…
Drawing · Perspective
