Freehand perspective and sketching; principles and methods of expression in the pictorial representation of common objects, interiors, buildings and landscapes (1916)
Norton, Dora Miriam · Brooklyn : The author · leaf 137
s different fromthe stool in our first interior study (Ch. XXXIII) inthat the sides are not parallel to each other (see plan, —.„ _^.- :_ Fig. 189). Also t the seat is atrifle lowerin the back,so that linesB, B (Fig. 190)slope down-ward towardthe back. Butthe chair issymmetrical onits center… … Fig. 188 A CHAIR L I \ PLAN OF 5CAT paper and located the eye level, the next step is to take the direc-tion of the front and side of the seat (lines A and B, Fig. 190).Leaving line A for the present we carry line B out, obtainingVPl. The feet, being on the horizontal floor, fall in lines…
Drawing · Perspective
