Freehand perspective and sketching; principles and methods of expression in the pictorial representation of common objects, interiors, buildings and landscapes (1916)
Norton, Dora Miriam · Brooklyn : The author · leaf 176
-7-x A. Perspective- SHOVl/lNG STAKEFORESHORTENED … B. Side view of stake - showing howits foreshortening- occurs. Fig. 244 surface, because its decrease of diameter is toward the eye level,while in the actual object it is away from the eye level. Now since it is like the cup reversed we see that any point(as A) in the cup, must be reflected…
Drawing · Perspective
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
