e, note that inorder to secure therequired height inthe completed pyra-mid, the length {xyin Fig. 141) of eachtriangular side pieceof the pyramid pat-tern is measuredfrom xy in Fig. 142,where the truelength of a side faceis shown. The facex-y-z in Fig. 142leans back, makingx-o foreshortened.…
