Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 591
Mitre Lines onMouldings. Assume that two pieces of cornice mouldingare to be joined at right angles ; that is, anangle of 90°. Let the section of the mould-ing be as shown in Fig. 1794. Draw the planof the mouldings and mitre as at Fig. 1795.Then set a bevel to the mitre line c d. Thiswill be the… … Fig. 1792 Fig. 1794
Carpentry · Joinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
