Freehand perspective and sketching; principles and methods of expression in the pictorial representation of common objects, interiors, buildings and landscapes (1910)
Norton, Dora Miriam · Brooklyn : D. M. Norton · leaf 157
ndrical Picture Plane.— Looking at Fig. 220, we findthat the middle cylinder, whichdoes appear right to the eye,extends equally each side of thecentral direction of seeing, sothat the picture plane is parallelto the apparent breadth of thecylinder. By drawing the othercylinders as if each had such… … A. Pl/\n.\ Showing UbE OF SPEC/AL PICTURE \^,,PLANES-THE ^ •EQUIVALENT OFTHE CylINORi-CML PICTURE.PLANE . TEYE
Drawing
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
