on is measured downward on acontinuation of the oblique gable edgeF beyond its lower end (z); and throughthis point a line parallel to B (that is, vanishing with it in VP2)forms the eaves. (The estimation of these last measurements bythe eye forms an important part of the students training… … Fig. 117 THE STUDY AND DRAWING OF A HOUSE
