Gas-engines and producer-gas plants; a practice treatise setting forth the principles of gas-engines and producer design, the selection and installation of an engine, conditions of perfect operation, producer-gas engines and their possibilities, the care of gas-engines and producer-gas plants, with a chapter on volatile hydrocarbon and oil engines (1905)
Mathot, Rodolphe Edgard, 1866- · New York N.W. Henley Pub. Co · leaf 100
linder drained by means ofthe drain-cock V (Fig. £;9), mounted at the inlet of theengines water-jacket. In order that the pressure ofthe atmosphere may not prevent the flowing of thewater, the highest part of the pipe is provided with asmall tube, T, communicating with the atmosphere.On account of… … Fig. 60.—Vanne sluice-cock. Water-Tanks.—The reservoir is mounted in such away that its base is flush with the top of the cylinder; itshould be as near as possible to the cylinder in order toobviate the use of long inlet and return pipes. Thisfact, however, does not necessarily render it…
Gas · Internal combustion engines
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
