Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 84

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 84
Steam Pipe, Ij^^-^.^VAk^^JAV^.^KVVAVg^^gZa L^^ … The cylinders are separated somewhat and have a sleeve betweenthe heads, which is bolted to the front head of low-pressure cylinder.At the front it is held by a flange which makes a joint around it. Thisallows easy inspection and repair of low-pressure piston, as the sleevein question slides into…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
