Gas-engines and producer-gas plants; a practice treatise setting forth the principles of gas-engines and producer design, the selection and installation of an engine, conditions of perfect operation, producer-gas engines and their possibilities, the care of gas-engines and producer-gas plants, with a chapter on volatile hydrocarbon and oil engines (1905)

Mathot, Rodolphe Edgard, 1866- · New York N.W. Henley Pub. Co · leaf 21

An illustration from Gas-engines and producer-gas plants; a practice treatise setting forth the principles of gas-engines and producer design, the selection and installation of an engine, conditions of perfect operation, producer-gas engines and their possibilities, the care of gas-engines and producer-gas plants, with a chapter on volatile hydrocarbon and oil engines, 1905, leaf 21
Fig. 3.—Second cycle: Compression. … Fig. 4.—Third cycle: Explosion and expansion. The Fourth Veriod.—Exhaust: The piston returnsa second time. The exhaust-valve is opened, and theproducts of combustion are discharged (Fig. 5).
