Gas-engines and producer-gas plants; a practice treatise setting forth the principles of gas-engines and producer design, the selection and installation of an engine, conditions of perfect operation, producer-gas engines and their possibilities, the care of gas-engines and producer-gas plants, with a chapter on volatile hydrocarbon and oil engines (1905)
Mathot, Rodolphe Edgard, 1866- · New York N.W. Henley Pub. Co · leaf 269
ylinder r is provided with a piston />,about the stem of which a spring s is coiled. A clocktrain contained in the chamber h unwinds the strip ofpaper from the roll /> and draws it over the drum p\where the pencil / leaves its mark. The tape is thenrewound on the spindle />. A small stylus… … Fig. 136.—R. Mathots continuous explosion recorder. the explosions, the cylinder c is provided with a casinge in which wat:;r is circulated by means of a small rub-ber tube which fits over the nipple c. This recorder THE EXPLOSION RECORDER 271 analyzes with absolute precision the work of all…
Gas · Internal combustion engines
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
