two branch pipes the minimum diameter DIAMETER OF PIPES 8i which meets this requirement is ascertained as follows:Draw to any scale a semicircle having a diameterequal or proportional to that of the main pipe (Fig.50). The sides of the isosceles triangle inscribed with-in this semicircle give the… … FiG. 51. sure of the gas and according to the load at which theengine is to run. This renders it possible to open thecock always to the same point (Fig. 51). Air Suction.—In a special chapter the precautions-tobe taken to counteract the influence of the suction of theengine in causing vibration…
