The gasoline engine on the farm; a practical, comprehensive treatise on the construction, repair, management and use of this great farm power as applied to all farm machinery and farmer's work indoors and out .. (1913)

Putnam, Xenophon Whiting, 1867- · New York, The Norman W. Henley Pub. Co. · leaf 82

An illustration from The gasoline engine on the farm; a practical, comprehensive treatise on the construction, repair, management and use of this great farm power as applied to all farm machinery and farmer's work indoors and out .., 1913, leaf 82
mall a part wouldbe insignificant, while the certainty of at least a holepunched through the piston head in case of a broken 8o The Gasoline Engine on the Farm pin would be almost absolute. In the best enginesthe pin is ground to fit the piston bosses and is some-times forced into place under… … Fig. 21.—^larine Type of Bushed Connecting Rod, engines the distance between bearings is relativelygreat and the rod must be heavier in proportion. Onthe other hand, a short rod tends to cramp the pistonin the cylinder and increases the friction by side-thrust. Some engine builders favor drop…

Internal combustion engines · Farm engines

Internet Archive · University of Connecticut Library · Public Domain Mark 1.0. Free to use for anything.
