Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing (1921)

International Correspondence Schools · Scranton, PA : International Textbook Co. · leaf 132

An illustration from Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing, 1921, leaf 132
u … 54 PROJECTION DRAWING §2 For practical purposes, it may safely be assumed that thetwo principal vanishing points are twice as far apart as theeye is from the object. If, then, it is desired to draw theperspective of a 4-inch cube as it would appear 24 inchesfrom the eye, proceed to lay out the…
