Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing (1921)

International Correspondence Schools · Scranton, PA : International Textbook Co. · leaf 226

An illustration from Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing, 1921, leaf 226
^ 76 FREEHAND AND ORNAMENTAL DRAWING §3 lines of ironwork split and branch into separate scrolls,cover the joint with drawing of a conventionalized leaf,the details of which have just been studied. The length,size, and proportions of the different parts of the leaf mustbe judged by the eye,…

Architectural drawing · Geometrical drawing · Brush drawing · Perspective · Projection · Decoration and ornament

Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
