60 ELEMENTARY PERSPECTIVE DRAWING §5 true height on the corner of the arch xy, which is in thepicture plane, and projecting- it to its true place by a linetoward V, as shown; or, after locating /, a line may be drawnthrough / toward V^—the vanishing point of lines inclinedat an angle of 45° above…
