Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing (1921)

International Correspondence Schools · Scranton, PA : International Textbook Co. · leaf 454

An illustration from Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing, 1921, leaf 454
on top of the brickwall, and is also rabbeted to receive the sash when it swingsinto place. 43. In Fig. 14 is shown another form of a similarwindow somewhat more elaborate and so arranged as toreceive a wire screen in front to keep out animals when thewindow is left open for ventilation. In this… … Detail OF Balanced 5a5h In Brick Wall Z^ i-°\K 5T0NE5IU_ BRICK -APRON

Architectural drawing · Geometrical drawing · Brush drawing · Perspective · Projection · Decoration and ornament
