Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing (1921)

International Correspondence Schools · Scranton, PA : International Textbook Co. · leaf 482

An illustration from Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing, 1921, leaf 482
DRAWING 67 Draw the upper landing 3 0 square, and then show fourtreads about 10 or IT wide from the landing to the plat-form. The platform is 3 0 wide and 4 S long to outsideof the rail, and there is one tread beyond it extending intothe hall. The posts, or newels, are 6 square, elevations ofthese… … tr-^^ij
