Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing (1921)

International Correspondence Schools · Scranton, PA : International Textbook Co. · leaf 534

An illustration from Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing, 1921, leaf 534
orms ofthese doors. At [a) is a plain door similar to Fig. 53 (r),except that the stile is \\ thick; {b) is also similar toFig. 53 (f), but the panel is thicker in the center. A panel §7 ARCHITECTURAL DRAWING 91 like this is called a raised panel. At {c) is shown the bestform for one of these cheap… … Fig. 54 For high-quality doors fir ished in hardwood, it is necessaryto use veneer glued to a built-up core. A few forms of built-up cores are shown in Fig. 55. At {a) the core consists offive pieces of pine a glued together to form a solid plank.The end-piece b and the surface c are of oak,…

Architectural drawing · Geometrical drawing · Brush drawing · Perspective · Projection · Decoration and ornament

Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
