To take off 3 miles, 2 furlongs, and 3 chains, one point will beon the primary division 3, and the other where the secondarydivision 2 intersects the tertiary division 3. These points aremarked by two small crosses on the scale. 88 GEOMETRICAL DRAWING AND DESIGN. 132. To take off any number to… … lOLOMtrJlES Fig. 186. Comparative Diagonal Scales useful for transferring thevalue of quantities in onemeasure to another. Tomake the scales less cum-bersome they are soarranged that in somecases the number to betaken off must be halved.With this proviso, anyquantity may be convertedfrom one scale…
