EXAMINATION PAPERS. 251 ^11. Redraw the given figure, altering the proportions of the parts sothat the sides of the four corner panels shall be exactly half those of thecentre panel. Make the side of the outside square 3, and the marginsthroughout 02 wide. (16) D 1 I D D 1 1 D Q. II. ^12. Draw an… … 252 GEOMETRICAL DRAWING AND DESIGN. IV. SECTION A. 1. Six feet are represented on a drawing by one inch. Make a scalefor the drawing by which single feet can be measured up to 40, and showinches diagonally. Figure the scale properly, and show by two small marks on it how youwould take off a…
