qual togiven line C. Draw a triangle with theside DE equal to given lineA, the side DF equal to PROBLEMS. 2^ given line B, and the third side FE equal to twice the givenmedian C. Bisect the line FE at G. Join DG and produce i*^to H, making GH equal to DG ; join EH.DEH will be the triangle required.… … be the triangle Quadrilaterals. To construct a square on a given base AB.C At point A erect AC perpen-dicular to AB and equal to it.With B and C as centres, andradius equal to AB, draw inter-secting arcs meeting at D ; joinDC and DB. CABD is the square required. Fig. 52.26. To construct a square on…
